4.2.1. Default Modem Baud Rate (Sw1, Sw2)
SetUp Switches one and two select the default baud rate for the SRM’s internal modem and the
serial Modem Port. The Modem Baud Rate can also be selected via the Modem Parameters
Menu (/M). Note that if the unit is reset to default parameters, the Modem Baud Rate will
return to the default setting selected by SetUp Switches one and two.
Note: Automatic baud rate sensing is disabled. This allows the SRM to function
with devices that do not send an AT command string.
Default Modem Baud Rate Sw1 Sw2
9600 bps * Down Down
38.4K bps Down Up
19.2K bps Up Down
2400 bps Up Up
* = Factory Setting
4.2.2. Default Flow Control Format (Sw3)
SetUp Switch three selects the default flow control (handshaking) format for the serial Modem
Port. The flow control format for the serial Modem Port can also be selected via the Modem
Parameters Menu. The flow control format for the internal modem itself is set using AT
commands as described in Section 9. Note that if the unit is reset to default parameters, the
flow control format will return to the default setting selected by SetUp Switch three.
Default Flow Control Format Sw3
RTS/CTS (Hardware) * Down
XON/XOFF (Software) Up
* = Factory Setting
4.2.3. Default Bits and Parity (Sw4)
SetUp Switch four selects the default bits and parity setting for both the internal modem and
the serial Modem Port. The bits and parity can also be selected via the Modem Parameters
Menu (/M). Note that if the unit is reset to default parameters, bits and parity will return to the
default setting selected by SetUp Switch four.
Default Bits and Parity Sw4
8 Bits, No Parity, 1 Stop Bit * Down
7 Bits, Even Parity, 1 Stop Bit Up
* = Factory Setting
4-2
SRM-100 - Secure Rack Modem, User's Guide Hardware Installation
