5.2. The General Parameters Menu
The menu shown in Figure 5.2 is used to set the Real Time Clock, and select the System
Password, Site ID, and other general parameters. To access the General Parameters Menu,
activate the SRM command mode as described in Section 5.1, then type /G and press [Enter].
To change the setting for any item in this menu, key in the number for the desired item, press
[Enter], then follow the instructions in the submenu. The General Parameters Menu includes
the following items:
1. System Password: This password protects modem access to the Command Mode. When
a caller connects to the SRM-100, a password prompt is sent. If the System Password is
entered, the caller will then be granted access to the SRM Command Mode. Note that the
System Password is case sensitive. (Up to 16 characters, Default = SUPER).
2. System Dial Back #: When defined, the SRM will dial this number before allowing
modem access to the Command Mode. When a caller contacts the SRM, a password
prompt is sent. If the caller enters the valid System Password, the SRM will disconnect
and then call the System Dial Back number. When the System Dial Back number
answers, the SRM Command Mode will start. (Up to 32 characters, Default = undefined).
Note: While a Dial Back operation is in progress, the SRM is not able to accept
incoming calls, and will not recognize commands entered via the Console Port.
3. Site ID: Defines a text string which can be used to identify the location where the SRM-
100 is installed. The Site ID message will be displayed at the top of the SRM Help
Screen. (Up to 32 characters, Default = undefined).
4. Real Time Clock: Sets the SRM's internal real time clock and calendar. The SRM uses
the Real Time Clock to record times and dates when logging connection activity. Enter
the correct time using 24 hour (military) format.
5-3
SRM-100 - Secure Rack Modem, User's Guide Set-Up and Configuration
GENERAL PARAMETERS
1.
System Password: SUPER
2. System Dial Back #: (undefined)
3. Site ID: (undefined)
4. Real Time Clock: Tue 06/13/2000 11:25:26
5. Console Port Communication: 9600, N, 8, 1
6. Command Echo: On
7. No Activity Timeout 5 Min
8. Password Attempts: 3
9. Password on Dial Back: Off
10. Security Mode: On
11. Audit Log Options: All
12. Dial Back Attempts: 1
13. Dial Back Delay: 30 Sec
Enter Selection,
Press to Abort ...
Figure 5.2: The General Parameters Menu
