Western Telematic SRM-100 - Manual (Page 48)

Register Range Default Function
S09 1 - 225 6 Carrier Detect Response Time. Determines the length of time (in tenths of a
second) required for the modem to recognize the receive character from the
remote modem, and turn on the DCD.
S10 1 - 255 14 Lost Carrier to Hang-Up Delay. Sets the length of time (in tenths of a
second) the modem will wait after loss of carrier before hanging up. If this
value is set lower than the value contained in S09, a loss of carrier will
always result in disconnection.
S11 50 - 255 95 Duration / Spacing DTMF. Sets the duration and spacing (in milliseconds)
between DTMF (touch tone) dialing characters.
S12 0 - 255 50 Escape Prompt Delay (EDP). Defines the maximum period (in fiftieths of a
second), allowed between receipt of the last character in the escape code
(+++), from the DTE and sending of the OK result code to DTE. If any
characters are detected during this time, the OK will not be sent.
S13 --- --- Not Used.
S14 --- --- Bit Mapped Options.
Bit
Option Val Descrip Cmd
0 Used Internally
1 Command Echo 0 Disabled E0
1 Enabled E1
2 Result Codes 0 Enabled Q0
1 Disabled Q1
3 Result Code Type 0 Numeric V0
1 Verbal V1
4 Used Internally
5 Dial Method 0 Tone T
1 Pulse P
6 Used Internally
7 Originate/Answer 0 Answer A
1 Originate D
S15 --- --- Not Used
S16 --- --- Modem Test Options.
Bit
Option Val Descrip Cmd
0 Local Analog Loopback 0 Disabled
1 Enabled &T1
1 Not Used
2 Local Digital Loopback 0 Disabled
1 Enabled &T3
3 Status Bit 0 Loopback Off
1 In Progress
4 Initiate Remote 0 Disabled
Digital Loopback 1 Enabled &T6
5 Remote Digital Loopback 0 Disabled
With Error Count 1 Enabled &T7
6 Local Analog Loopback 0 Disabled
With Self Test 1 Enabled &T8
7 Not Used
S17 --- --- Not Used.
10-2
SRM-100 - Secure Rack Modem, User's Guide S-Registers
