Advanced Features and Troubleshooting Manual 43
Color Sampler Charts for Phaser 750 Printers
Printing a color sampler chart from the Phaser 750
printer’s front panel
Note
Use the same color correction and print quality mode to print the chart and to
print from your application. Any other color correction or print quality mode
selections in the driver will cause colors to print differently than expected.
Selecting a color correction and a print quality mode
1. At the Ready message in the printer’s front panel, press Menu.
2. At the Menu Maps message, scroll to Print Quality, press Menu.
3. Scroll to Print Quality Modes, press Menu.
4. To change the selected print quality mode:
a. Scroll to More Choices, press OK.
b. Scroll to the selection you want, press OK. The display returns to the Print
Quality Modes level.
5. Scroll to TekColor Correction, press Menu.
6. To change the selected color correction:
a. Scroll to More Choices, press OK.
b. Scroll to the selection you want, press OK. The display returns to the TekColor
Correction level.
7. Press until the front panel reads Ready.
Printing a color sampler chart
1. At the Ready message in the printer’s front panel, press Menu.
2. At the Menu Maps message, scroll to Printer Demo, press Menu.
3. Scroll to RGB Sampler Prints or CMYK Sampler Prints, press Print.
4. For future reference, write the name of the color correction that you used on the first
page of the chart.
Printing the desired colors from an application
1. Using the color sampler chart that you printed earlier, select the desired colors.
2. From your application, apply the desired colors in your document by entering the
specific CMYK or RGB values as indicated on the sampler chart.
3. Print your document; select the same color correction and print quality mode that you
used to print the color sampler chart.
