Caring for Your Printer 5
User Manual 5-21
3. There are two sets of upper paper-feed rollers located above the
maintenance tray. One set of rollers is rubber; the other set is
white plastic. The rubber rollers are mechanically linked to
companion rubber rollers located under the maintenance tray.
Turning the lower rubber rollers also turns the upper rollers.
To clean the upper rubber rollers, use either the pre-packaged
alcohol-soaked cloth or fold a lint-free cloth into a two-inch square
and soak with alcohol.
Place the cleaning cloth against the underside of each upper
rubber roller, lifting to create pressure against the roller. Press the
middle finger of your other hand flat against a lower roller and
turn the roller using the entire length of your finger. The upper
rubber roller should rotate four or five complete revolutions to ensure
proper cleaning.
Scrub each roller thoroughly. If the cloth becomes dirty, discard it
and use another.
