E.4
Standard LCD Modes
Table E-3 Standard VGA LCD-Only Video Modes
Hex
Mode
Display
Mode
# of Gray
Shades
(Mono)
Number of
Colors
Char.
Per
Row
Char. Cell
(pixels)
Screen
Resolution
0, 1
Text
16/16
16/256K
40 x 25
8 x 16
360 x 400
2,3
Text
16/16
16/256K
80 x 25
8 x 16
720 x 400
4,5
Graphics
4/64
4/256K
40 x 25
8 x 8
320 x 200
6
Graphics
2/16
2/256K
80 x 25
8 x 8
640 x 200
7
Text
2/16
Mono.
80 x 25
8 x 16
720 x 400
D
Graphics
16/64
16/256K
40 x 25
8 x 8
320 x 200
E
Graphics
16/16
16/256K
80 x 25
8 x 8
640 x 200
F
Graphics
2/16
Mono.
80 x 25
8 x 14
640 x 350
10
Graphics
16/16
16/256K
80 x 25
8 x 14
640 x 350
11
Graphics
2/16
2/256K
80 x 30
8 x 16
640 x 480
12
Graphics
16/16
16/256K
80 x 30
8 x 16
640 x 480
13
Graphics
64/256
256/256K
40 x 25
8 x 8
320 x 200
Screen Standards E-5
