Table 6-6 Main Board, P/N 9798803-0001, Parts Listing (continued)
Item TI Part No. Quantity Description
Note: The following is a breakout of the tab parts associated with item 191.
PART NO: 9798803-6001 TAB PARTS FOR 9798803-0001 REV: R/AA
Item TI Part No. Quantity Description
04 9798803-3301 1 BACKSIDE PARTS FOR 9798803-0001
59 2563194-0001 1 IC,80502,64-BIT MICROPRCSR,75MHZ,CER TCP
U2
203 9798833-0001 1 PLATFORM,CPU,TM5000P
204 9798827-0001 1 TAB COVER,CPU,TM5000
205 9798828-0001 2 ADHESIVE STRIP,COVER,TM5000P
Note: The following is a breakout of the backside parts associated with item 04 above.
PART NO: 9798803-3301BACKSIDE PARTS FOR 9798803-0001 REV: R/AA
Item TI Part No. Quantity Description
03 9798803-3001 1 TOPSIDE PARTS FOR 9798803-0001
43 2548370-0002 1 IC,ACT32,QUAD 2-INPUT OR PLASTIC SOIC
U136
44 2563213-0003 1 IC,LM45B,TEMPERATURE SENSOR,PLSTC
SOT-23
RT140
47 2563135-0031 0 IC,DRAM,256K X 16,60NS,PLSTC,TSOP II
*ALTERNATE FOR P/N 2563135-32 (PRI)
*LM ITEM 220
*U83,U84
52 2220535-0004 1 IC,CURRENT SOURCE,LM334M,PLASTIC SOIC
U90
53 2563133-0003 1 IC,FDC37C665GT,SUPR I/O FLPY CONT,PL QFP
U15
55 2563195-0001 1 IC,2042,KYBD CONT/BUFFER LOGIC,PL QFP
U11
56 2563186-0002 4 IC,DRAM,1M X 16-BIT,70 NS MAX,PLSTC TSOP
U41 U42 U43 U44
60 2248623-0004 1 CRYSTAL OSC,14.3180 MHZ,+/-100PPM,SMT PK
U121
61 2248623-0016 1 XTAL,OSCILLATOR,50.0000 MHZ,+/-100,SMT
U120
62 2248623-0014 1 CRYSTAL,OSCILLATOR,33.333 MHZ,+/-100,SMT
U122
65 2563202-0002 1 IC,74LVT573,OCT TRANS D TYPE LCH,P TSSOP
U502
