Texas Instruments 5000 User Manual
Page 143
Table 6-3 TM5000, 10.4 TFT Color, 810HD, Domestic Unit Assembly,
P/N 9798843, Parts Listing (continued)
Item
TI Part No.
Quantity
Description
141
2248407-1307
2
SCREW,SLOT-TORX,PLASTITE,PAN,2-28 X .188
142
2248407-0073
3
SCREW,TORX,MACHINE,2-56 X .250
143
2248840-0002
2
SCREW,PLASTITE,PAN HEAD,PH,2-28 X .375
*ALT PN 2248407-0311(SEC)
*LM ITEM 130
144
9786222-0001
1
CABLE ASSY,LCD,LEFT,TM5000 SERIES
145
9786222-0002
1
CABLE ASSY,LCD,RIGHT,TM5000 SERIES
148
9798838-0001
1
FLEX CABLE,HARD DISK DRIVE,TM5000SERIES
149
9786226-0001
1
CABLE ASSY,FDD,TM5000 DX4
150
9786220-0001
1
SPEAKER ASSY,TM5000 SERIES
151
9798834-0002
1
WARRANTY LABEL,FCC,TAMPER EVIDENT,
TM5000
152
9798834-0001
1
WARRANTY LABEL,CPU,TM5000P
153
9786252-0001
1
CABLE EXTENSION MICROPHONE,TM5000
SERIES
154
9786251-0001
1
MEDALLION LABEL,TM5000 "P"
155
9786183-0001
1
SECURITY RING
162
9798813-0001
1
PWB ASSY,UNIVER IR TRANSCEIVER
163
9786249-0001
1
LENS COVER,IR,TM5000
168
9786295-0001
1
ADHESIVE PAD,HEATSINK,TM5000 SERIES
169
2247795-0023
1
WSHR,FL,NYLON,.194" ID,.437" OD,.030 THK
170
9786255-0001
1
COMPRESSION FOAM,STANDBY SWITCH,TM5000
171
9786256-0001
1
BUTTON,STANDBY SWITCH,TM5000 SERIES
172
2248238-0025
1
RING,RETAINING,PUSH-ON,STNLS STL
173
2211933-0024
2
SPR,CPRSN,MUSIC W,4.6 LB/IN SPR RT,9/16L
174
9786294-0001
1
SPEAKER GRILL ASSY,TM5000 SERIES
175
2248938-0001
1
VALOX STRIP,.5 WIDE X 1.5 LONG
176
9798846-0001
1
INSULATOR,HDD/PCMCIA,TM5000 SERIES
177
9798846-0002
1
INSULATOR,HDD DOOR,TM5000 SERIES
178
9798846-0003
1
INSULATOR,HEATSINK,BASE,TM5000 SERIES
179
2248989-0001
AR
TAPE,PSA,POLYCRBNT,1.0" W X .0055" T,CLR
180
9786302-0001
1
HEATSINK,BASE,TM5000 SERIES
181
9786280-0001
1
PLATE,HEATSINK,TM5000 SERIES
185
2211895-0004
3
SCREW,TORX,SLOTTED,2-28 X.375",CARBON
186
2248836-0003
2
CORE,FERRITE,SPLIT,FPC
187
2247871-0001
AR
TAPE,TRANSFER,ADHESIVE,.005" THICK
188
9798846-0004
1
INSULATOR,MAIN BOARD,TM5000 SERIES
190
0972146-0006
.0080
TUBING,HEAT SHRINK,.250 ID, BLACK
191
0972146-0006
.0040
TUBING,HEAT SHRINK,.250 ID, BLACK
6-8 Illustrated Parts Listing
