Table 6-3 TM5000, 10.4 TFT Color, 810HD, Domestic Unit Assembly,
P/N 9798843, Parts Listing
PART NO: 9798843-0001 UNIT ASSY, MDL 5557, 810HD, 10.4 TFT, DOM
REV: J/ M
Item TI Part No. Quantity Description
01 9798843-0100 1 COMMON PARTS FOR 9798843-XXXX
02 9786285-0101 1 HDD,2.5 IN,810HD,DOS 6.22 PRELOAD
03 9791004-0001 1 KEYBOARD,BROTHER,W/POINTER,DOMESTIC
Note: The following is a breakout of the common parts associated with P/N 9798843 (item 1
above).
PART NO: 9798843-0100 COMMON PARTS FOR 9798843-XXXX REV: J/ M
Item TI Part No. Quantity Description
50 9786069-0001 1 BASE,TM5000
51 9786227-0001 1 COVER ASSY,TOP,TM5000 SERIES
54 9786073-0001 2 CONNECTOR DOOR,TM5000
55 9786074-0001 1 PCM DOOR,TM4100
57 9786250-0003 1 LCD ASSY,10.4" TFT SHARP,TM5000 SERIES
58 9786072-0005 1 BEZEL.LCD,SHARP 10X TFT,TM5000
60 9786079-0001 1 LIGHT PIPE,BASE,TM5000
61 9786080-0001 1 BUTTON,BATTERY EJECT,LEFT,TM5000
62 9786081-0001 1 BUTTON,BATTERY EJECT,RIGHT,TM5000
63 9786082-0001 1 BUTTON,POWER SWITCH,TM5000
65 9786084-0001 1 DOOR,HARD,DRIVE,TM5000
66 9786085-0001 1 HINGE COVER,RIGHT,TM5000
68 9786297-0001 1 HINGE COVER ASSY,LEFT,TM5000
71 9786090-0001 2 LATCH,BUTTON,TM5000
72 9786091-0001 1 RAM CARD,FRONT TRIM,TM4100
77 9786096-0001 2 SPRING,PAWL,LILY
78 9786097-0001 1 HINGE,RIGHT,CONSTANT TORQUE,TM4100
79 9786098-0001 1 HINGE,LEFT,CONSTANT TORQUE,TM4100
81 9786100-0001 1 HINGE,BRACKET,RIGHT,TM5000
82 9786101-0001 1 HINGE,BRACKET,LEFT,TM5000
84 9786103-0001 1 PAWL,RIGHT,TM5000
85 9786104-0001 1 PAWL,LEFT,TM5000
86 9786184-0001 1 BRACKET,LEFT,FLOPPY DRIVE,TM4100
90 9786109-0001 1 BRACKET,FLOPPY DRIVE,LILY
91 9786110-0001 1 RELEASE ARM,I/O DOOR,RIGHT,TM4100
92 9786111-0001 1 RELEASE ARM,I/O DOOR,LEFT,TM4100
93 9786112-0001 1 RELEASE BUTTON,I/O DOOR,TM4100
94 9786113-0001 1 PIN,MOUNTING,.340 LONG,TM5000
95 9786114-0001 1 SPRING,I/O DOOR LATCH,LILY
96 9786115-0001 1 EXTENSION SPRING,I/O DOOR,TM5000
6-6 Illustrated Parts Listing
