Page 137

6.2
TM5000 Pentium, 10.4 TFT
810HD, Domestic Notebook with
Pack, P/N 9798842-0001
Figure 6-1 and Table 6-2 contain an illustration and parts listing for the
TM5000 Pentium 10.4 inch TFT, 810 Drive, TI Part No. 9798842-0001
(Domestic version only shown for clarity).
Figure 6-1
Figure 6-1 TM5000 Pentium, 10.4 TFT, 810HD, Domestic Notebook with Pack,
P/N 9798842-0001
6-2 Illustrated Parts Listing
