Table 6-6 Main Board, P/N 9798803-0001, Parts Listing (continued)
Item TI Part No. Quantity Description
141 9786236-0001 1 INDUCTOR,13UH,5 AMP,TM5000 SERIES
L201
142 2248749-0010 1 CAP,AL ELECT,ORG,100UF,10%,20V,RAD LEADS
C201
143 2248730-0018 1 CAP,AL ELECT,68UF,20%,25V,RADIAL
C206
165 2248730-0012 1 CAP,AL ELECT,100UF,20%,16V,RADIAL
C190
171 2248863-0105 1 RES,CHIP,220 K OHM,5%,.063W,0603 PKG
R1911
186 9786170-0001 4 CONTACT,BATTERY OUTER,TM4100
P182 P183 P184 P185
187 9786171-0001 6 CONTACT,BATTERY INNER,TM4100
P210 P211 P212 P213
P180 P181
191 9798803-6001 1 TAB PARTS FOR 9798803-0001
202 9786093-0001 1 CONNECTOR,BRACKET,TM5000
207 2248566-0001 6 JACKSCREW,HEX HEAD,.500" LONG
208 2363830-0008 .0030 LABEL,SYMBOLIZATION (.375" X .375")
209 0415804-0007 AR SEALING,COMPOUND,RETAINING, PURPLE, E
224 2248863-0027 1 RES,CHIP,120 OHM,5%,.063W,0603 PKG
R1210
226 9786311-0001 1 GROUND CLIP,SPRING,TM5000 SERIES
*ALT PN 9786313-0001(SEC)
*LM ITEM 230
227 2248812-0001 4 WIRE,PRECUT,STPD,SOLID,30AWG,.250"L,WHT
228 2248812-0002 2 WIRE,PRECUT,STPD,SOLID,30AWG,.300"L,WHT
230 9786313-0001 0 GROUND CONTACT,MAINBOARD,MODIFIED
*ALT PN 9786311-0001(PRI)
*LM ITEM 226
231 2248812-0036 1 WIRE,PRECUT,STPD,SOLID,30AWG,8.00"L,WHT
232 2248812-0015 1 WIRE,PRECUT,STPD,SOLID,30AWG,1.00"L,WHT
233 2248812-0006 1 WIRE,PRECUT,STPD,SOLID,30AWG,.500"L,WHT
234 2265966-0010 2 TAPE, FOAM, DOUBLE STICK, 3.8MM X 3.8MM
6-16 Illustrated Parts Listing
