E.3
Extended VGA Modes
Table E-2 - External Monitors Extended VGA Modes
Hex Mode
Display Mode
Number of
Colors
Resolution
Refresh Rate
11
a
Graphics
2/256
640 x 480
72
11
a
Graphics
2/256
640 x 480
75
11a
Graphics
16/256
640 x 480
72
12
a
Graphics
16/256
640 x 480
75
14
Text
16/256
1056 x 400
70
54
Text
16/256K
1056 x 350
70
55
Text
16/256K
1056 x 350
70
58, 6A
c
Graphics
16/256K
800 x 600
56
58, 6A
Graphics
16/256K
800 x 600
60
58, 6A
Graphics
16/256K
800 x 600
72
58, 6A
Graphics
16/256K
800 x 600
75
5C
Graphics
256/256K
800 x 600
56
5C
Graphics
256/256K
800 x 600
60
5C
a
Graphics
256/256K
800 x 600
72
5C
a
Graphics
256/256K
800 x 600
75
5D
Graphics
16/256K
1024 x 768
43
5D
Graphics
16/256K
1024 x 768
60
