Table 6-12 Inverter PWB, P/N 9786134-0001, Parts Listing (continued)
Item TI Part No. Quantity Description
20 2563148-0001 2 XSTR,MOSFET,N-CHN,50VDS,25AID,50W,TO-252
Q12,Q14
23 2248600-0061 1 CAP,CER CHIP,.1 UF,20%,50V,Z5U,0805 PKG
C22
25 2248600-0055 1 CAP,CER CHIP,33000 PF,10%,50V,X7R,0805 P
C11
26 2248600-0037 2 CAP,CER CHIP,1000 PF,10%,50V,COG,805 PKG
C13,C14
29 2248601-0049 1 CHIP RESISTOR,1.0K OHM,.1W,5%,0805 PKG
R4
32 2248601-0073 1 CHIP RESISTOR,10K OHM,.1W,5%,0805 PKG
R40
40 2248601-0081 1 CHIP RESISTOR,22K OHM,.1W,5%,0805 PKG
R51
43 2248846-0243 1 RES,CHIP,3.32 K OHM,1%,.10W,0805 PKG
R24
44 2248601-0041 3 CHIP RESISTOR,470 OHM,.1W,5%,0805 PKG
R32,R36,R50
46 2248601-0097 1 CHIP RESISTOR,100K OHM,.1W,5%,0805 PKG
R41
47 2248846-0314 1 RES,CHIP,18.2 K OHM,1%,.10W,0805 PKG
R42
48 2248601-0001 1 CHIP RES,10 OHM,.1 W,5%,0805 PKG
R46
52 2548508-0001 1 MOSFET,P-CHANNEL,60V,SOT-23 PKG
Q5
53 2548468-0001 1 FET,BST82,N-CHANNEL,80V VDS,PLAS SOT-23
Q6
54 2563150-0001 1 XSTR,CHIP,NPN GP,45 V,500 M AIC,SOT-23
Q13
55 2248813-0104 1 RES,CHIP,1.00 OHM,1%,1W,2512 PKG
R57
62 2548579-0010 1 XSTR,9430,MOSFET,SNGL P-CHAN,ENHANC,8-P
Q18
Illustrated Parts Listing 6-49
