Table 6-6 Main Board, P/N 9798803-0001, Parts Listing (continued)
Item
TI Part No.
Quantity
Description
Note: The following is a breakout of the topside parts associated with item 003 above.
PART NO: 9798803-3001 TOPSIDE PARTS FOR 9798803-0001 REV: R/AA
Item
TI Part No.
Quantity
Description
01
9798804-0001
1
PWB,LILY MAIN (TM5000P)
27
2248870-0001
1
CONN,PLUG,60-POS,5MM STK,0.8MM PITCH,SMT
P141
34
2248500-0054
1
FLAT CABLE CONN,ZIF,26-POS,1MM CTR,2-ROW
P22
35
2248930-0001
1
HEADER,EXPANSION CARD CONN,2-ROW,
136-POS
P40
36
2248879-0001
1
CONN,RCPT,140-POS,13MM STK,0.8MM PITCH,S
P140
37
2248919-0001
2
HEADER,STRAIGHT,20-POS,2-ROW,1.25MM,
SMT
P91 P92
41
2248956-0001
1
RECEPTACLE,2MM PITCH,8-POS,2-ROW,RT ANG
P150
42
2542400-0004
1
IC,TLC555,TIMER,PLASTIC SOIC
U184
46
9798845-0002
1
SYSTEM BIOS,V.1.0,TM5000P
U111
47
2563135-0031
0
IC,DRAM,256K X 16,60NS,PLSTC,TSOP II
*ALTERNATE FOR P/N 2563135-32 (PRI)
*LM ITEM 220
*U81,U82
49
2563192-0001
1
IC,2056,CONTROLLER,PLASTIC QFP
U3
50
2563176-0001
1
IC,GD7428,VIDEO CONTROLLER,PLASTIC QFP
U8
51
2563193-0001
1
IC,2188,PCI CONTROLLER,PLASTIC QFP
U7
54
2548416-0016
1
IC,RS232 XCVR,3-DRVRS,5-RCVRS,PLSTC SSOP
U160
57
2563189-0001
9
IC,SRAM,32K X 8-BIT,15 NS MAX,PLSTC SOJ
U51 U52 U53 U54
U55 U56 U57 U58
U59
58
2563188-0002
1
IC,RTC-6583,REAL TIME CLOCK-W/RAM,P SOIC
U112
