Table 6-3 TM5000, 10.4 TFT Color, 810HD, Domestic Unit Assembly,
P/N 9798843, Parts Listing (continued)
Item TI Part No. Quantity Description
103 9786147-0001 1 BUTTON,LCD,CONTRAST,BRIGHTNESS,TM5000
104 9786123-0001 1 HEATSINK,CPU,TM5000
105 9786259-0001 1 HEATSINK CUSHION,TM5000 SERIES
106 9786128-0001 1 PWB ASSY,LED BOARD,LILY
107 9786148-0001 1 PWB ASSY,SLEEP SWITCH,LILY
110 9798803-0001 1 PWB ASSY,MAIN BOARD,TM5000P
111 9786205-0001 1 PWB ASSY,PCMCIA/SOUND BOARD,TM4100
112 9786209-0001 1 PWB ASSY,KEYSCAN BD (II),TM4100
113 9786185-0001 1 MICROFLOPPY DRIVE,11 MM,TM4100 (LILY)
115 9786161-0001 1 LBL,SINGLE SHT,LASER PRINTABLE,#9
116 9786161-1005 REF LABEL,RATING (REF)
117 9786161-1008 REF LABEL,BARCODE/SERIAL ID/P/N (TRAVELER)
118 9786161-1009 REF LABEL,BARCODE/SERIAL ID/P/N,UNIT (REF)
119 9786161-1002 REF LABEL,INT’L AGENCY(REF)
120 9786161-1020 REF LABEL,COPYRIGHT (REF)
121 9798807-0001 REF SET UP IN ERROR
122 9786162-0001 1 NAMEPLATE,TM5000
126 9786177-0001 2 COVER,LCD SCREWS,TM5000
127 0418331-0012 0 SCREW,MACHINE,FLAT HEAD,4-40 X .188,PHIL
*ALT PN 2248976-0012(PRI)
*LM ITEM 137
128 2248407-0056 3 SCREW,TORX,PLASTITE,PAN,2-28 X .500
129 2248407-0128 2 SCREW,TORX,PLASTITE,4-20 X .250
130 2248407-0311 0 SCREW,TORX,PLASTITE,PAN,2-28 X .375
*ALT PN 2248840-0002(PRI)
*LM ITEM 143
131 2248407-0071 2 SCREW,TORX,MACHINE,BUTTON,2-56 X .1250
132 2581299-0003 4 SCREW,W/THREAD LOCK,M2.5X3,PAN,CROS
RECE
133 2248407-1306 4 SCREW,SLOT-TORX,MACHINE,PAN,4-40 X .188
134 2248407-0309 2 SCREW,TORX,MACHINE,FLAT,4-40 X .375
135 2248340-0007 4 SCREW,METRIC,TORX,MACH,FLH,M3-0.5 X 6
136 2211895-0406 3 SCREW,TORX,4-20 X.375",CARBON STEEL
137 2248976-0012 4 SCREW,MACH,FLAT,PH,4-40 X .188
*ALT PN 0418331-0012(SEC)
*LM ITEM 127
138 2248407-0310 2 SCREW,TORX,MACHINE,PAN,4-40 X .125
139 2248407-0078 6 SCREW,TORX,MACHINE,4-40 X .250
140 2248407-0315 1 SCREW,TORX,PLASTITE,PAN,4-20 X 1.125
Illustrated Parts Listing 6-7
