Table 6-7 PCMCIA/Sound Board, P/N 9786205-0001, Parts Listing
(continued)
Item TI Part No. Quantity Description
C20 C21
80 2248600-0037 2 CAP,CER CHIP,1000 PF,10%,50V,COG,805 PKG
C13 C37
83 2248600-0042 2 CAP,CER CHIP,2700PF,10%,50V,X7R,805 PKG
C31 C33
84 2248600-0017 2 CAP,CER CHIP,22 PF,10%,50V,COG,805 PKG
C164 C165
85 2248731-0001 1 CAP,TANT CHIP,4.7 UF,20%,10V,1206 PKG
C108
86 2221947-0015 1 CAP,CERAMIC,470 PF,50V,10%,COG,CHIP
C32
88 2248600-0049 3 CAP,CER CHIP,10000PF,10%,50V,X7R,805 PKG
C22 C23 C158
89 2221092-0006 1 IC,74HCT244,OCTAL BFR/LINE DRVR,PL TSSOP
U36
90 2248873-0021 7 CAP,TANT CHIP,CNFML,15.0 UF,20%,16V,B CA
C2 C12 C72 C105
C117 C119 C167
91 2248834-0001 4 CAP,TANT CHIP,CNFRML,100UF,20%,15V,H-PKG
C86 C168 C180 C181
94 2248846-0114 2 RES,CHIP,150 OHM,1%,.10W,0805 PKG
R35 R36
95 2248601-0049 1 CHIP RESISTOR,1.0K OHM,.1W,5%,0805 PKG
R153
99 2248601-0080 4 CHIP RES,20 K OHM,.1 W,5%,0805 PKG
R124 R143 R80 R81
100 2248601-0033 2 CHIP RESISTOR,220 OHM,.1W,5%,0805 PKG
R145 R154
101 2248601-0081 1 CHIP RESISTOR,22K OHM,.1W,5%,0805 PKG
R44
104 2248601-0061 1 CHIP RESISTOR,3.3K OHM,.1W,5%,0805 PKG
R49
107 2248846-0431 1 RES,CHIP,301 K OHM,1%,.10W,0805 PKG
R155
108 2248601-0013 1 CHIP RESISTOR,33 OHM,.1W,5%,0805 PKG
R129
111 2248601-0017 1 CHIP RESISTOR,47 OHM,.1W,5%,0805 PKG
R144
6-30 Illustrated Parts Listing
