TANDBERG Gatekeeper User Guide
Page 15 of 105
3.3. Unpacking
The TANDBERG Gatekeeper is delivered in a special shipping box which should contain the following
components:
 Gatekeeper unit
 Installation sheet
 User manual and other documentation on CD
 Rack-ears and screws
 Kit with 4 rubber feet
 Cables:
o
Power cables
o
One Ethernet cable
o
One null-modem RS-232 cable
3.4. Mounting
The Gatekeeper comes with brackets for mounting in standard 19" racks.
Before starting the rack mounting, please make sure the TANDBERG Gatekeeper is placed securely on a
hard, flat surface.
1.
Disconnect the AC power cable.
2. Make sure that the mounting space is according to the Installation site preparations in section
3.2.
3. Attach the brackets to the chassis on both sides of the unit.
4. Insert the unit into a 19" rack, and secure it with screws.
3.5. Connecting the Cables
3.5.1. Power cable
Connect the system power cable to an electrical distribution socket.
3.5.2. LAN cable
Connect a LAN cable from the LAN 1 connector on the front of the unit to your network.
3.5.3. Null-modem RS-232 cable
Connect the supplied null-modem RS-232 cable between the Border Controller's Data 1 connector and
the COM port on a PC.
3.6. Switching on the System
To start the TANDBERG Gatekeeper:
1.
Ensure the power cable is connected.
2. Ensure the LAN cable is connected.
3. Switch the power switch button on the back of the unit to '1'.
On the front of the chassis you will see the Power LED being lit.
