Getting Started
34 K1297-G20 Monitor User Manual
Removing Modules
If you remove modules, proceed as follows:
1. Switch the device off and unplug the mains plug.
2. Unscrew the two cross-head screws of the module’s front cover. The
screws must be completely loosened.
3. Use your thumbs to simultaneously press outwards the levers located
beneath the screws.
4. Then pull the module carefully out of the device. Make sure that the
spring strip on the long side of the module cover is not being damaged.
5. If the two springs located behind the screws on the internal side of the
module’s front cover catch when removing the module, press the
springs carefully back using an appropriate tool. Then pull the module
completely out of the device.
