Getting Started
32
K1297-G20 Monitor User Manual
K1297.
Make sure that the hex switches are set as follows:
Table 2: Setting the VME bus address
Board
Slot
Hex switch number
PC board
1
9
AP-4 board
2
0
Interface board 1
8
1
Interface board 2
7
2
Interface board 3
6
3
Interface board 4
5
4
Interface board 5
4
5
Interface board 6
3
6
K1297 Compact.
Make sure that the hex switches are set as follows:
Table 3: Setting the VME bus address
Board
Slot
Hex switch number
PC board
1
9
AP-4 board
2
–
Interface board 1
5
1
Interface board 2
4
2
Interface board 3
3
3
