Appendix A: Interfaces
A-46
K1297-G20 Monitor User Manual
Table A–27: V.24 Monitor (Cont.)
Pin
Assignment
Pin
Assignment
9
Not connected
22
125 ring indicate (IN)
10
Not connected
23
111 clk select (IN)
11
116 select DCE STDBY (IN)
24
113 ext. clock (IN)
12
Not connected
25
142 test indicator (IN)
13
Not connected
