Getting Started
K1297-G20 Monitor User Manual
29
The following figures give you an example which measuring board you
can put into which slot:
K1297. Possible Board Combination
8 7 6 5 4 3 2 1 0
P
C
Board
PC Board
BAI S
0
Board
E1/DS1 Board
AP-4 Board
E1/DS1 Board
E1/DS1 Board
E1/DS1 Board
BAI
S
0
Board (Power Feeding)
K1297 Compact. Possible Board Combination
5 4 3 2 1 0
Ethernet
Board
PC Board
PC Board
BAI Board
AP-4 Board
E1/DS1 Board
NOTE. K1297 and K1297 Compact. For each interface board a cable is
delivered free of charge. Thus you are able to work right away with your
Protocol Tester. Furthermore, we offer a wide range of cables and
adapters, which you can order. For further information please take a look
at our data sheet or contact your local sales partner.
