Table C–6: Interface boards
VME-bus backplane
Layers with automatic daisy chain and 5 VME slots:
slot 1, system computer; slots 3, 4, 5, interface modules
Interface modules
(except Ethernet)
CPU 68EC040 (25 MHz) with up to 32 MByte RAM
With E1/DS1: 4 additional RISC processors 68360
(QUICC) for I/O tasks
Application Processor
AP–4
Power PC 750, 350 MHz, 1 MB L 2 Cache,
64 MB RAM
with the following connectors:
1 x RJ45 Serial
1 x RJ45 10-BaseT/100-BaseTx Ethernet
Application Processor
AP–4/256
Power PC 750, 350 MHz, 1 MB L 2 Cache,
256 MB RAM
with the following connectors:
1 x RJ45 Serial
1 x RJ45 10-BaseT/100-BaseTx Ethernet
BAI
Interface module for performing measurements on ISDN
S
0
and U
2B1Q
lines with the following connectors:
2 x monitoring (duplex)
E1/DS1 (PRIMO)
Interface module for performing measurements on
PCM-24 and PCM-30 lines with the following connectors:
quadruple monitoring (duplex)
V./X.
Interface module for performing measurements on V.24,
X.21 or V.35 lines with the following connectors:
2 x monitoring (duplex)
