Appendix A: Interfaces
A-18 K1297-G20 Monitor User Manual
Table A–12: Pin assignment for interface SCSI I/O
Pin Assignment Pin Assignment
1 Ground 26 D0
2 Ground 27 D1
3 Ground 28 D2
4 Ground 29 D3
5 Ground 30 D4
6 Ground 31 D5
7 Ground 32 D6
8 Ground 33 D7
9 Ground 34 DP
10 Ground 35 Ground
11 Ground 36 Ground
12 Ground 37 Ground
13 Ground 38 TERMPWR
14 Ground 39 Ground
15 Ground 40 Ground
16 Ground 41 ATN
17 Ground 42 Ground
18 Ground 43 BSY
19 Ground 44 ACK
20 Ground 45 RST
21 Ground 46 MSG
22 Ground 47 SEL
23 Ground 48 C/D
24 Ground 49 REQ
25 Ground 50 I/O
