Appendix A: Interfaces
A-50 K1297-G20 Monitor User Manual
9-pin D-Sub connectors are available as interfaces.
Table A–28: Pin assignment D-Sub connectors
Pin Assignment Pin Assignment
1 RX– MON A, C, E, G 6 RX+ MON A, C, E, G
2 Not connected 7 Not connected
3 Not connected 8 Not connected
4 Not connected 9 RX+ MON B, D, F, H
5 RX– MON B, D, F, H
In addition a headphone connector with a mini jack is provided for
listening to audio data.
NOTE. Use a headphone with a ferrit part in order to fulfill EMC
regulations.
The status LEDs on the front panel have the following meaning:
Synchronous: Receive frame recognized, if LED is on.
Signal ok: Receive signal recognized, if LED is on.
Blinking LED Port is configured for data receiving, but no valid signal
is received
Off Port has not yet been configured
On Board is beeing booted (after reset) or port is configured
and valid signal is received.
