Appendix A: Interfaces
A-10 K1297-G20 Monitor User Manual
Ethernet BNC Interface (10Base-2)
K1297. The ethernet BNC socket is on the rear of the device on the PC
module front panel.
K1297 Compact. The ethernet BNC socket is on top of the device on the PC
module front panel.
1
Table A–6: Pin assignment for interface 10Base–2
Pin Assignment Pin Assignment
1 RXI/TXo 2 CDS (Signal ground)
