Tektronix K1297-G20 User Manual
Page 25
Getting Started
K1297-G20 Monitor User Manual
13
K1297 Compact: Setting-up the Device
Proceed as follows when setting up the device:
1. Press in both of the lateral handle hinges (handle variant: push up
hinges), fold down the handle and set the device in the desired
position.
2. Pull the dark grey handle above the logo and lift the keyboard from the
device.
The handle can now be used as keyboard rest.
The mains connector and the ON/OFF switch are both located on the right
side of the device. The fuses are located underneath the switch cover.
