2.4.6 PLL Controller Divider 2 Register (PLLDIV2)
2.4.7 PLL Controller Divider 3 Register (PLLDIV3)
PLL Controller
The PLL controller divider 2 register (PLLDIV2) is shown in Figure 9 and described in Table 15 . Divider 2
controls divider for SYSCLK2. PLLDIV2 is not used on PLLC2.
Figure 9. PLL Controller Divider 2 Register (PLLDIV2)
31 16
Reserved
R-0
15 14 5 4 0
D2EN Reserved RATIO
R/W-1 R-0 R/W-2h
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 15. PLL Controller Divider 2 Register (PLLDIV2) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reserved
15 D2EN Divider 2 enable.
0 Divider 2 is disabled.
1 Divider 2 is enabled.
14-5 Reserved 0 Reserved
4-0 RATIO 0-1Fh Divider ratio. Divider value = RATIO + 1. For example, RATIO = 0 means divide by 1.
The PLL controller divider 3 register (PLLDIV3) is shown in Figure 10 and described in Table 16 . Divider 3
controls divider for SYSCLK3. PLLDIV3 is not used on PLLC2.
Figure 10. PLL Controller Divider 3 Register (PLLDIV3)
31 16
Reserved
R-0
15 14 5 4 0
D3EN Reserved RATIO
R/W-1 R-0 R/W-5h
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 16. PLL Controller Divider 3 Register (PLLDIV3) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reserved
15 D3EN Divider 3 enable.
0 Divider 3 is disabled.
1 Divider 3 is enabled.
14-5 Reserved 0 Reserved
4-0 RATIO 0-1Fh Divider ratio. Divider value = RATIO + 1. For example, RATIO = 0 means divide by 1.
SPRUES0B – December 2007 Phase-Locked Loop Controller (PLLC) 25
