4-10 AUDIO OPERATIONS
Monitor 1 Receive
Monitor 1 Send
Select A Only
A-only Pan
B-only Pan
Select A+B
A+B A Pan
Select B Only
A+B B Pan
From Send A
From Send B
From Rec A
From Rec B
To rest of
Monitor 1 Circuitry
Adjusting individual monitor panning
Scroll down the
Audio settings
screen and you’ll see four submenu entries, one for each
of the four monitor outputs:
The four submenus have identical structures:
Select which setting you want to adjust by highlighting it and pressing
EDIT
. The position
indicator (
) will start flashing to indicate it’s active. Turn
EDIT
to move it toward the left
or right. If there’s signal playing through that monitor, you can hear it pan in your
headphones. When you’ve adjusted any setting’s pan the way you want it, press
EDIT
to
confirm.
Panning is continuous and can be completely arbitrary. In the screen shots above, the
A
setting
is just slightly to the left of center.
