2005 CAMRY (EWD586U)

Starting and Ignition for 2AZ–FE

I15 Ignition SW

2–1 : Closed with the ignition SW at ST position
7–6 : Closed with the ignition SW at ON or ST position
7–8 : Closed with the ignition SW at ST position

A4 Park/Neutral Position SW (A/T)

4–5 : Closed with the A/T shift lever in P or N position

S2 (A), S3 (B) Starter

Point closed with the Park/Neutral position SW at P or N position and the ignition SW at ST position (A/T)
Point closed with the clutch start SW on and the ignition SW at ST position (M/T)

: Parts Location

Code

See Page

Code

See Page

Code

See Page

38 (*2)

39 (*2)

E10

I15

39 (*2)

: Relay Blocks

Code

See Page

Relay Blocks (Relay Block Location)

Engine Room R/B (Engine Compartment Left)

: Junction Block and Wire Harness Connector

Code

See Page

Junction Block and Wire Harness (Connector Location)

Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)

(

)

Engine Wire and Engine Room J/B (Engine Compartment Left)

Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)

Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)

: Connector Joining Wire Harness and Wire Harness

Code

See Page

Joining Wire Harness and Wire Harness (Connector Location)

IF1

Engine Room Main Wire and Instrument Panel Wire (Right Side of Steering Column Tube)

IF6

Engine Room Main Wire and Instrument Panel Wire (Right Side of Steering Column Tube)

IL1

Engine Wire and Instrument Panel Wire (Behind the Glove Box)

: Ground Points

Code

See Page

Ground Points Location

48 (*2)

Left Side of Cylinder Head

Cowl Side Panel LH

: Splice Points

Code

See Page

Wire Harness with Splice Points

Code

See Page

Wire Harness with Splice Points

E11

48 (*2)

Engine Wire

E15

48 (*2)

Engine Wire

E12

48 (*2)

Engine Wire

Engine Room Main Wire

* 1 : 1MZ–FE, 3MZ–FE

* 2 : 2AZ–FE

* 3 : w/ Power Seat

* 4 : w/o Power Seat

Service Hints
