2005 CAMRY (EWD586U)
143
T7 Turn Signal Flasher Relay
1–Ground : Approx. 12 volts with the ignition SW at ON or ST position
4–Ground : Always approx. 12 volts
7–Ground : Always continuity
: Parts Location
Code See Page Code See Page Code See Page
A13 A 40 F11 38 (*2) J22 A 41
A40 B 40
F12
36 (*1) J23 B 41
C7 A 40
F12
38 (*2) R6 43
C11 40 H10 41 R7 43
F11 36 (*1) J2 41 T7 41
: Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1B 25 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
2G 28 Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
2K 28 Floor Wire and Driver Side J/B (Lower Finish Panel)
2M
2N 29 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
2R
( )
3A
34 Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)
3B
34 Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)
: Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IF3 50 Engine Room Main Wire and Instrument Panel Wire (Right Side of Steering Column Tube)
: Ground Points
Code See Page Ground Points Location
EB
46 (*1)
Right Fender EB
48 (*2)
Right Fender
EC
46 (*1)
Left Fender EC
48 (*2)
Left Fender
II 50 Cowl Side Panel LH
IJ 50 Instrument Panel Brace LH
BQ 54 Front Side of Rear Quarter Wheel House LH
BS 54 Lower Back Panel Center
: Splice Points
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
B11 54 Floor Wire
* 1 : 1MZ–FE, 3MZ–FE * 2 : 2AZ–FE * 3 : w/ Power Seat * 4 : w/o Power Seat
Service Hints
