TOYOTA 2005 CAMRY - Manual (Page 159)

2005 CAMRY (EWD586U)
306
J POWER SOURCE (Current Flow Chart)
Engine Room J/B (See Page 24)
Fuse System Page
5A ALT–S Charging 72
5A ST
Combination Meter
Starting and ignition (1MZ–FE, 3MZ–FE)
Starting and ignition (2AZ–FE)
260
64
68
10A ETCS
Cruise Control (1MZ–FE, 3MZ–FE)
Cruise Control (2AZ–FE)
Engine Control (1MZ–FE, 3MZ–FE)
Engine Control (2AZ–FE)
192
198
74
86
10A HEAD LH UPR
Headlight
Multiplex Communication System (BEAN)
120
104
10A HEAD RH UPR
Headlight
Multiplex Communication System (BEAN)
120
104
10A HORN
Horn
Multiplex Communication System (BEAN)
Theft Deterrent and Door Lock Control
236
104
152
10A IG2
ABS (TMC Made)
ABS (TMMK Made)
Charging
Combination Meter
Cruise Control (1MZ–FE, 3MZ–FE)
Cruise Control (2AZ–FE)
Electronically Controlled Transmission and A/T Indicator
(1MZ–FE, 3MZ–FE)
Electronically Controlled Transmission and A/T Indicator (2AZ–FE)
Engine Control (1MZ–FE, 3MZ–FE)
Engine Control (2AZ–FE)
Seat Belt Warning
SRS
VSC
176
180
72
260
192
198
204
210
74
86
224
185
170
15A HAZ Turn Signal and Hazard Warning Light 142
15A IGN
Clock
Engine Control (1MZ–FE, 3MZ–FE)
Engine Control (2AZ–FE)
Engine Immobilizer System
Starting and ignition (1MZ–FE, 3MZ–FE)
Starting and ignition (2AZ–FE)
246
74
86
100
64
68
20A EFI
Cruise Control (1MZ–FE, 3MZ–FE)
Cruise Control (2AZ–FE)
Electronically Controlled Transmission and A/T Indicator
(1MZ–FE, 3MZ–FE)
Electronically Controlled Transmission and A/T Indicator (2AZ–FE)
Engine Control (1MZ–FE, 3MZ–FE)
Engine Control (2AZ–FE)
192
198
204
210
74
86
∗
These are the page numbers of the first page on which the related system is shown.
