2005 CAMRY (EWD586U)
101
T11 Transponder Key Computer
1–Ground : Always approx. 12 volts
2–Ground : Approx. 12 volts with ignition SW at ON or ST position
14 (TMMK Made), 16 (TMC Made)–Ground : Always continuity
10 (TMMK Made), 3 (TMC Made)–Ground : Continuity with the key in cylinder
: Parts Location
Code See Page Code See Page Code See Page
A13 A 40 E7 40 J23 B 41
A40 C 40 H10 B 41 T11 41
D3 40 I14 41 U1 41
D6 42 J22 A 41
: Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1B 25 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
2M
29 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
2R
29 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
3A
34 Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)
3B
34 Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)
: Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IC2 50 Instrument Panel Wire and Floor Wire (Left Kick Panel)
IF1 50 Engine Room Main Wire and Instrument Panel Wire (Right Side of Steering Column Tube)
IJ1 52 Instrument Panel Wire and Instrument Panel Wire (Instrument Panel Reinforcement RH)
: Ground Points
Code See Page Ground Points Location
II 50 Cowl Side Panel LH
* 1 : 1MZ–FE, 3MZ–FE * 2 : 2AZ–FE * 3 : w/ Power Seat * 4 : w/o Power Seat
Service Hints
