2005 CAMRY (EWD586U)

147

S14 Stop Light SW

2–1 : Closed with the brake pedal depressed

: Parts Location

Code

See Page

Code

See Page

Code

See Page

H12

42

N4

43

R7

43

J11

42

R6

43

S14

41

: Junction Block and Wire Harness Connector

Code

See Page

Junction Block and Wire Harness (Connector Location)

2G

28

Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)

2K

28

Floor Wire and Driver Side J/B (Lower Finish Panel)

: Ground Points

Code

See Page

Ground Points Location

BQ

54

Front Side of Rear Quarter Wheel House LH

BS

54

Lower Back Panel Center

: Splice Points

Code

See Page

Wire Harness with Splice Points

Code

See Page

Wire Harness with Splice Points

B5

54

Floor Wire

B8

54

Floor Wire

B6

54

Floor Wire

B11

54

Floor Wire

Service Hints
