TOYOTA 2011 Yaris Sedan User Manual
Abbreviation/acronym list
384
Abbreviation list
Abbreviation/Acronym list
ABBREVIATIONS
MEANING
ABS
Anti-Lock Brake System
ACC
Accessory
ALR
Automatic Locking Retractor
CRS
Child Restraint System
ECU
Electronic Control Unit
EDR
Event Data Recorder
ELR
Emergency Locking Retractor
EPS
Electric Power Steering
GAWR
Gross Axle Weight Ratings
GVWR
Gross Vehicle Weight Rating
I/M
Emission inspection and maintenance
LATCH
Lower Anchors and Tethers for Children
LED
Light Emitting Diode
LT
Light truck
M + S
Mud + Snow
MMT
Methylcy clopentadienyl Manganese Tricarbonyl
MTBE
Methyl Tertiary Butyl Ether
OBD
On Board Diagnostics
ODO
Odometer
RES
Resume
SRS
Supplemental Restraint System
TIN
Tire Identification Number
TPMS
Tire Pressure Warning System
TRAC
Traction Control
TWI
Treadwear Indicators
VIN
Vehicle Identification Number
VSC
Vehicle Stability Control
