TOYOTA 2005 CAMRY - Manual (Page 120)

2005 CAMRY (EWD586U)
137
Body ECU
9–Ground : Approx. 12 volts with the ignition SW at ON or ST position
12, 24–Ground : Always continuity
1–Ground : Always approx. 12 volts
D6, D7, D8, D9 Door Courtesy SW Front LH, RH, Rear LH, RH
1–Ground : Closed with each of the door open
: Parts Location
Code See Page Code See Page Code See Page
B6 A 40 D8 42 L4 43
B8 C 40 D9 42 L5 43
C7 A 40 G4 42 N4 43
C8 B 40 I13 41 V9 43
D4 42 I14 41 V10 43
D6 42 I17 42
D7 42 J23 41
: Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
2B 28 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
2K 28 Floor Wire and Driver Side J/B (Lower Finish Panel)
2M
2Q
29 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
2R
29 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
2S
3A 34 Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)
: Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IC2 50 Instrument Panel Wire and Floor Wire (Left Kick Panel)
IE1 50 Instrument Panel Wire and Roof Wire (Inside of Front Left Pillar)
IN4 52 Instrument Panel Wire and Floor No.2 Wire (Right Kick Panel)
: Ground Points
Code See Page Ground Points Location
II 50 Cowl Side Panel LH
IJ 50 Instrument Panel Brace LH
IM 50 Instrument Panel Reinforcement RH
: Splice Points
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
B1
54 Roof Wire
B5 54 Floor Wire
B2
54 Roof Wire
* 1 : 1MZ–FE, 3MZ–FE * 2 : 2AZ–FE * 3 : w/ Power Seat * 4 : w/o Power Seat
Service Hints
