Audio System for Separate Type Amplifier
R4 (A) Radio and Player
(A)11–Ground : Approx. 12 volts with the ignition SW at ACC or ON position
(A) 1–Ground : Always approx. 12 volts
(A)20–Ground : Always continuity
S12 (A), S13 (B) Stereo Component Amplifier
(B) 2–Ground : Approx. 12 volts with the ignition SW at ACC or ON position
(A) 7–Ground : Always approx. 12 volts
(A)13–Ground : Always continuity
: Parts Location
Code
See Page
Code
See Page
Code
See Page
C10
40
R8
43
S13
B
41
F6
42
R9
43
T9
41
F7
42
R13
B
41
T10
41
R4
A
41
S12
A
41
: Junction Block and Wire Harness Connector
Code
See Page
Junction Block and Wire Harness (Connector Location)
2A
28
Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
: Connector Joining Wire Harness and Wire Harness
Code
See Page
Joining Wire Harness and Wire Harness (Connector Location)
IB2
50
Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IH1
IH2
50
Instrument Panel Wire and Instrument Panel No.2 Wire (Instrument Panel Brace RH)
IH3
(
)
IM2
52
Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
IN2
52
Instrument Panel Wire and Floor No.2 Wire (Right Kick Panel)
: Ground Points
Code
See Page
Ground Points Location
IL
50
Instrument Panel Brace RH
: Splice Points
Code
See Page
Wire Harness with Splice Points
Code
See Page
Wire Harness with Splice Points
I3
52
Instrument Panel No.2 Wire
Service Hints
