2005 CAMRY (EWD586U)
303
I
: Ground Points
Code See Page Ground Points Location
EA
46 (*1)
EA
48 (*2)
Right Fender
EB
46 (*1)
Right Fender
EB
48 (*2)
EC
46 (*1)
EC
48 (*2)
Left Fender
ED
46 (*1)
Left Fender
ED
48 (*2)
EE 46 (*1) Left Side of Cylinder Head
EF 46 (*1) Right Side of Cylinder Head
EG 48 (*2) Left Side of Cylinder Head
EH 48 (*2) Intake Side of Cylinder Block
II 50 Cowl Side Panel LH
IJ
50 Instrument Panel Brace LH
IK
50 Instrument Panel Brace LH
IL 50 Instrument Panel Brace RH
IM
50 Instrument Panel Reinforcement RH
IN
50 Instrument Panel Reinforcement RH
BO 54 Under the Driver’s Seat
BP 54 Under the Front Passenger’s Seat
BQ 54 Front Side of Rear Quarter Wheel House LH
BR 54 Front Side of Rear Quarter Wheel House RH
BS 54 Lower Back Panel Center
: Splice Points
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
E1
46 (*1) I5
52 Engine Wire E1
48 (*2) I6
52 Engine Wire
E2
46 (*1) B1 54 Roof Wire
E2
48 (*2)
Engine Room Main Wire
B4 54 Front Door LH Wire
E3
46 (*1)
Engine Room Main Wire
B10
54 Floor Wire E3
48 (*2) B11
54 Floor Wire
E4
46 (*1) B13 54 Front Door RH Wire
E4
48 (*2) B16
54 Floor Wire
E6 46 (*1)
Engine Wire
B17
54 Floor Wire
E11 48 (*2)
Engine Wire
* 1 : 1MZ–FE, 3MZ–FE * 2 : 2AZ–FE * 3 : w/ Power Seat * 4 : w/o Power Seat
