2005 CAMRY (EWD586U)
127
FOG Relay
5–3 : Closed with the light control SW at HEAD position, dimmer SW at LOW position and fog SW on
: Parts Location
Code See Page Code See Page Code See Page
C11 40 F1 38 (*2) F2 38 (*2)
F1 36 (*1) F2 36 (*1) J4 41
: Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
1 22 Engine Room R/B (Engine Compartment Left)
: Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
2C 28 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
2G 28 Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
2R 29 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
3A 34 Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)
: Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IF2 50 Engine Room Main Wire and Instrument Panel Wire (Right Side of Steering Column Tube)
: Ground Points
Code See Page Ground Points Location
EB
46 (*1)
Right Fender EB
48 (*2)
Right Fender
EC
46 (*1)
Left Fender EC
48 (*2)
Left Fender
IK 50 Instrument Panel Brace LH
: Splice Points
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
E10 46 (*1) Engine Room Main Wire E10 48 (*2) Engine Room Main Wire
* 1 : 1MZ–FE, 3MZ–FE * 2 : 2AZ–FE * 3 : w/ Power Seat * 4 : w/o Power Seat
Service Hints
