2005 CAMRY (EWD586U)
316
K CONNECTOR LIST
1 2
(TMC Made) Black
F12
1 2 3
(TMMK Made) Black
F12
1
G 1
2 1
3 4
Black
G 2
1 2
Black
G 3
1 2 3 4 5
G 4
1 2
Black
H 1
1 2
Brown
H 2
1 2
Black
H 3
1 2
Brown
H 4
1 2
3 4
(1MZ–FE, 3MZ–FE) Dark Gray
H 6
2 1
3 4
(2AZ–FE)
H 6
2 1
3 4
Black
H 7
1
Black
H 8
1
Black
H 9
4
18
3
17 20
1
21 19
5 2
22
6
23
7
25
9
26
10
27
11
28
12
29
13
30
14
31
15
32
16
24
8
H10
3
8
2 1
7 6 5 4
H11
1 2
(*1)
H12
1 2
(*2) Gray
H12
2 1
3 4
(*3) Dark Gray
H13
2 1
3 4
(*4) Black
H13
1 2 3 4
Black
I 1
1 2 3 4
Black
I 2
1 2 3 4
Black
I 3
1 2 3 4
Black
I 4
1 2 3 4
Black
I 5
1 2 3 4
Black
I 6
1 2
(1MZ–FE, 3MZ–FE) Gray
I 7
1 2
(2AZ–FE) Gray
I 7
1 2
(1MZ–FE, 3MZ–FE) Gray
I 8
1 2
(2AZ–FE) Gray
I 8
1 2
(1MZ–FE, 3MZ–FE) Gray
I 9
1 2
(2AZ–FE) Gray
I 9
1 2
(1MZ–FE, 3MZ–FE) Gray
I10
1 2
(2AZ–FE) Gray
I10
*1 : w/ Rear Spoiler
*2 : w/o Rear Spoiler
*3 : 2AZ–FE California TMC Made
*4 : 2AZ–FE California TMMK Made
