2005 CAMRY (EWD586U)
145
TAIL Relay
5–3 : Closed with the light control SW at TAIL or HEAD position
C11 Combination SW
14–16 : Closed with the light control SW at TAIL or HEAD position
: Parts Location
Code See Page Code See Page Code See Page
B6 A 40
F10
36 (*1) L1 43
C11 40
F10
38 (*2) L2 43
F9
36 (*1) J4 41 R6 43
F9
38 (*2) J11 42 R7 43
: Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
1 22 Engine Room R/B (Engine Compartment Left)
: Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
2E
28 Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
2G
28 Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
2K 28 Floor Wire and Driver Side J/B (Lower Finish Panel)
: Ground Points
Code See Page Ground Points Location
EB
46 (*1)
Right Fender EB
48 (*2)
Right Fender
EC
46 (*1)
Left Fender EC
48 (*2)
Left Fender
IK 50 Instrument Panel Brace LH
BQ 54 Front Side of Rear Quarter Wheel House LH
BS 54 Lower Back Panel Center
: Splice Points
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
B3 B10
54 Floor Wire
B8 54 Floor Wire B11
54 Floor Wire
B9
* 1 : 1MZ–FE, 3MZ–FE * 2 : 2AZ–FE * 3 : w/ Power Seat * 4 : w/o Power Seat
Service Hints
