2005 CAMRY (EWD586U)
141
TAIL Relay
5–3 : Closed with the light control SW at TAIL or HEAD position
C11 Combination SW
14–16 : Closed with the light control SW at TAIL or HEAD position
: Parts Location
Code
See Page
Code
See Page
Code
See Page
A13
A
40
C8
B
40
R3
B
41
A36
40
C10
40
R4
41
A40
B
40
C11
40
R5
41
B6
A
40
G3
41
R13
41
C4
40
H10
41
S4
41
C5
40
J4
41
S5
41
C7
A
40
R2
A
41
: Relay Blocks
Code
See Page
Relay Blocks (Relay Block Location)
1
22
Engine Room R/B (Engine Compartment Left)
: Junction Block and Wire Harness Connector
Code
See Page
Junction Block and Wire Harness (Connector Location)
2E
28
Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
2M
29
Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
2R
29
Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
3A
34
Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)
3B
34
Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)
: Connector Joining Wire Harness and Wire Harness
Code
See Page
Joining Wire Harness and Wire Harness (Connector Location)
IH1
50
Instrument Panel Wire and Instrument Panel No 2 Wire (Instrument Panel Brace RH)
IH2
50
Instrument Panel Wire and Instrument Panel No.2 Wire (Instrument Panel Brace RH)
: Ground Points
Code
See Page
Ground Points Location
II
50
Cowl Side Panel LH
IJ
50
Instrument Panel Brace LH
IK
50
Instrument Panel Brace LH
* 1 : 1MZ–FE, 3MZ–FE
* 2 : 2AZ–FE
* 3 : w/ Power Seat
* 4 : w/o Power Seat
Service Hints
