Combination Meter

B2 Brake Fluid Level Warning SW

1–2 : Closed with the float down

C7 (A) Combination Meter

(A) 21, (A) 27–Ground : Approx. 12 volts with the ignition SW at ON or ST position

(A) 1–Ground : Always approx. 12 volts

(A)15, (A) 20, (B) 12–Ground : Always continuity

O1 Oil Pressure SW

1–Ground : Continuity with the oil pressure above approx. 20 kpa (2.8 psi, 0.2 kgf/cm

)

: Parts Location

Code

See Page

Code

See Page

Code

See Page

36 (*1)

39 (*2)

38 (*2)

37 (*1)

39 (*2)

37 (*1)

: Relay Blocks

Code

See Page

Relay Blocks (Relay Block Location)

Engine Room R/B (Engine Compartment Left)

: Junction Block and Wire Harness Connector

Code

See Page

Junction Block and Wire Harness (Connector Location)

Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)

Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)

Floor Wire and Driver Side J/B (Lower Finish Panel)

Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)

(

)

Instrument Panel Wire and Passenger Side J/B (Instrument Panel Brace RH)

: Connector Joining Wire Harness and Wire Harness

Code

See Page

Joining Wire Harness and Wire Harness (Connector Location)

IC1

Instrument Panel Wire and Floor Wire (Left Kick Panel)

IF1

IF2

Engine Room Main Wire and Instrument Panel Wire (Right Side of Steering Column Tube)

IF3

Engine Room Main Wire and Instrument Panel Wire (Right Side of Steering Column Tube)

IF4

IL2

Engine Wire and Instrument Panel Wire (Behind the Glove Box)

: Ground Points

Code

See Page

Ground Points Location

46 (*1)

Right Fender

48 (*2)

Right Fender

46 (*1)

Left Fender

48 (*2)

Left Fender

Cowl Side Panel LH

Instrument Panel Brace LH

* 1 : 1MZ–FE, 3MZ–FE

* 2 : 2AZ–FE

* 3 : w/ Power Seat

* 4 : w/o Power Seat

Service Hints
