The automatic light control system works when the light control SW is turned to AUTO. The automatic light control sensor
detects the brightness around the vehicle. By this function, the system automatically turns the taillight and headlight on if the
brightness is below the regular level and turns the taillight and headlight off when the surroundings become brighter than the
regular level.

Body ECU

9–Ground : Approx. 12 volts with the ignition SW at ON or ST position

12, 24–Ground : Always continuity

1–Ground : Always approx. 12 volts

D6 Door Courtesy SW Front LH

1–Ground : Continuity with the driver’s door open

: Parts Location

Code

See Page

Code

See Page

Code

See Page

A28

C11

J23

: Relay Blocks

Code

See Page

Relay Blocks (Relay Block Location)

Engine Room R/B (Engine Compartment Left)

: Junction Block and Wire Harness Connector

Code

See Page

Junction Block and Wire Harness (Connector Location)

Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)

Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)

Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)

Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)

: Connector Joining Wire Harness and Wire Harness

Code

See Page

Joining Wire Harness and Wire Harness (Connector Location)

IC2

Instrument Panel Wire and Floor Wire (Left Kick Panel)

: Ground Points

Code

See Page

Ground Points Location

Cowl Side Panel LH

Instrument Panel Brace LH

System Outline

Service Hints
