Determining Actual Radar Range
The actual maximum radar range is essentially line-of-sight, and is
limited by the height of the scanner and the height of the target as
shown below lists some range examples:
Radar Range
Antenna Height (m)
Target Height (m)
Maximum Range (nm)
3
3
7.8
3
10
10.9
5
3
8.9
5
10
12.0
Note:
The ranges shown in the table are theoretical maximum
ranges. The radar horizon is greater than the optical
horizon, but the radar can only detect targets if a large
enough target is above the radar horizon.
