RayTech Navigator User’s Guide
5-24
Moving a VRM/EBL
You can control VRM/EBL separately or together.
To move a VRM or EBL:
1. Click the VRM/EBL button on the Pathfinder Panel.
2. Click the button that corresponds to what you want to
modify: VRM/EBL 1 or VRM/EBL 2 . A drop-down
dialog box for the selected VRM/EBL appears.
3. Click VRM/EBL On to display the selected VRM/EBL on
the radar picture in its last-used position. The object is
displayed with dashed-lines.
4. From the drop-down dialog box, select the item that
corresponds to the action you want:
To Move: Click:
Selected VRM/EBL combination Edit VRM/EBL
Selected VRM only Edit VRM
Selected EBL only Edit EBL
5. The selected object is displayed as a solid line. The cursor
appears with arrows on all four corners.
6. Press and hold the left mouse button as you drag the EBL
to the new angle and/or change the VRM radius (range).
7. Release the mouse button to drop the VRM/EBL in its
new position. The object is again displayed with dashed-
lines.
