RayTech Navigator User’s Guide

A-10

Connecting to KVH Instruments

Navigator connects to KVH instruments via KVH’s NMEA Box or
Race Box interface devices. Connecting via the Race Box offer the
advantage of automatically sending Navigator data back to the KVH
system’s displays. If you use the Race Box, you will also need the
NMEA Box, because the Race Box doesn’t propagate all of the
NMEA data.

To connect to a KVH Race Box, refer to Figure A-1 and Table A-8.
(To connect to an NMEA Box, refer to “NMEA Basics,” earlier in
this appendix.)

Table A-8. Connecting Navigator to a KVH Race Box

Connect Cable Color:

To Race Box Terminal:

Yellow (Rx)

NMEA Interface Terminal 13 (Tx NMEA)

Blue (SGnd)

NMEA Interface Terminal 14 (Negative)

Green (Tx)

Race Interface Terminal 3 (Rx NMEA)

Black (SGnd)

Race Interface Terminal 5 (Negative)
