Appendix A – Connecting Peripheral Instruments
A-11
Connecting to Ockam Instruments
Navigator connects to Ockam instruments via Ockam’s Model 050D
RS-232 Interface (which you must supply). You must also set two
switches on the Ockam unit.
Note:
You can connect Navigator to any model Ockam
RS-232 Interface; however, to ensure optimum
reliability of the data transfer, we recommend
that you use Ockam Model 050D.
To connect to an Ockam Model 050D RS-232 Interface:
1. Set Switch
S1
on Model 050D to
4
.
2. Set Switch
S2
to
D
.
3. Refer to Figure A-1 and Table A-9 to make the required cable
connections.
Table A-9. Connecting Navigator to an Ockam 050D RS-232 Interface
Connect Cable Color:
To Ockam 050D Pin:
Yellow (Rx)
Pin 4
Blue (SGnd)
Not used
Green (Tx)
Pin 2
Black (SGnd)
Pin 1
