RayTech Navigator User’s Guide
4-22
Working With Waypoint Groups
You can create as many different groups of waypoints as you need,
and then manipulate the individual waypoints within those groups.
Waypoint groups can be added/deleted/renamed just like individual
waypoints, and waypoints can be swapped between groups, sent-to
and retrieved-from the Waypoint Recycle Bin.
To create a new waypoint group:
1. Select Edit Route from the Route menu, then click Waypoint
Properties to display the Waypoint Properties dialog box
(Figure 4-20).
2. As shown in Figure 4-20, click Groups to display the
Group Action popup menu.
3. Select New Waypoint Group . The Rename Waypoint Group
dialog box is displayed (Figure 4-21).
4. Type the name for the new group, then click OK .
Figure 4-21. Creating a New Waypoint Group
Click
Groups
on Waypoint
Properties dialog to display
Group Action popup, then
select
New Waypoint Group
