21
Making the Settings
Setup Guide
■
Connecting Two Pads to Trigger Inputs
5/6 (TOM2/AUX) and 7/8 (TOM3/4)
With the optional cable (PCS-31) or standard insert cable, two pads may be
connected to the trigger inputs 5/6 (TOM2/AUX) and 7/8 (TOM3/4).
For instructions on making these settings, refer to p. 69.
fig.P-012.e
When using an optional
PCS-31 or standard "insert"
cable (Stereo to dual mono
jacks) to connect two pads
to 1 input (5/6 or 7/8) rim
shots are not be possible.
If you use a single pad
(with rim shot function)
connected via a stereo
cable, then rim shots are of
course possible.
TD-6V Rear Panel
PD-8
