Chapter 3 Operation IPmux-16 Installation and Operation Manual
3-44 Configuring IPmux-16
Table 3-4. LAN Statistics
Statistics Parameters Description
MAC Address Hard-Coded Port local MAC address
Mode Half duplex or Full duplex Port mode is set by either the default mode or via auto
negotiation results
Rate 10Mbps or 100Mbps Port rate is set by either the default mode or via auto
negotiation results
Status Unconnected or Connected Unconnected: Link loss
Connected: Normal operation
Frames received from the user
Correct frames The total number of correct frames received
Correct Octets The total number of correct octets received
Alignment Errors A counter of frames received that are not an integral number
of octets in length (RFC 1643).
FCS Error A counter of frames received that do not pass the FCS check
(RFC 1643).
Frames transmitted to the network
Correct Frames The total number of frames successfully transmitted
Correct Octets The total number of octets successfully transmitted
Single Collision Valid only in half duplex mode
(RFC 1643) A counter of successfully transmitted frames for which
transmission is inhibited by exactly one collision.
Multiple Collision Valid only in half duplex mode
(RFC 1643) A counter of successfully transmitted frames for which
transmission is inhibited by more than one collision.
Deferred
Transmission
Valid only in half duplex mode
(RFC 1643)
A counter of frames for which the first transmission attempt
is delayed because the medium is busy.
Late Collision Valid only in half duplex mode
(RFC 1643)
The number of times that a collision is detected on a
particular interface later than 512 bit-times into the
transmission of a packet.
Carrier Sense Error Valid only in half duplex mode
(RFC 1643) The number of times that the carrier sense condition was
lost or never asserted when attempting to transmit a frame.
Slot/Channel: Select the LAN module and channel on which you want to view
statistics
Bundle Connection Status
Main Menu
↓
3. Performance
Monitoring
↓
2. Bundle
Connection Status
Type 2 (Bundle Connection Status) in the Performance Monitoring menu to view
Connectivity Status, Sequence Errors, Jitter Buffer Underflows and Overflows and
Next Hop Mac Address.
➤ To view Connection status:
1. Select a bundle by typing 1 and then the bundle number.
2. Press <Enter>.
To reset counters type R.
To view the next open connection type F.
